TRF-45 High Frequency PCB Solutions for Advanced RF Applications

September 20, 2025

As wireless and high-frequency technologies continue to advance, the demand for reliable, low-loss PCB materials has never been greater. Among the top-tier options available today is TRF-45, a high-performance laminate developed with Taconic’s advanced ceramic expertise.

Whether you're designing satellite communication systems, RFID tags, or GPS antennas, TRF-45 offers the electrical and mechanical properties needed to ensure signal integrity and long-term reliability.

What Is TRF-45?

TRF-45 is a high-frequency circuit board material reinforced with woven glass, offering exceptional dimensional stability and thermal performance. A key advantage of TRF-45 lies in its controlled Z-axis expansion, which remains stable across a broad temperature range — even during soldering processes.

What’s more, TRF-45 is fully compatible with standard PCB fabrication techniques, including shearing, drilling, milling, and plating, making it as practical as it is powerful.

Key Features of TRF-45

1.Excellent Electrical Properties

Dielectric Constant (Dk): 4.5 @ 10 GHz
Dissipation Factor (Df): 0.0035 @ 10 GHz
Ideal for high-frequency and RF applications with minimal signal loss.

2. Low Moisture Absorption

Moisture Absorption Rate: ≤ 0.06%
Ensures consistent performance even in humid environments.

3.High Mechanical Strength

Flexural Strength:
17,000 lbs/in (lengthwise)
15,000 lbs/in (transverse)

Offers robust physical support for complex assemblies.

4.Superior Thermal and Peel Strength

Peel Strength: > 8 lbs/in
CTE (Coefficient of Thermal Expansion):
X & Y-axis: 9 ppm/°C
Z-axis: 40 ppm/°C
Maintains structural integrity under thermal stress.

5. Safety Certified

UL 94 V-0 Rated
Meets stringent flammability standards for safe operation.

PCB Capabilities with TRF-45

We support a full range of design and manufacturing options to help you build the perfect high-frequency PCB:

Configurations: Double-sided, multilayer, and hybrid PCBs
Copper Weight: 1 oz (35µm) or 2 oz (70µm)
Thickness Options: 8mil, 16mil, 24mil, 32mil, 40mil, 64mil, 120mil
Max Board Size: Up to 400mm x 500mm
Solder Mask Colors: Green, black, blue, yellow, red, purple
Surface Finishes: Bare copper, HASL, ENIG, immersion silver, immersion tin, ENEPIG, pure gold, OSP

With these options, you can optimize performance, thermal management, and aesthetics for any application.

Applications

TRF-45 is trusted in a variety of demanding RF and wireless applications, including:

Satellite radio antennas
RFID antennas
GPS antennas
Automotive radar systems
5G infrastructure
Aerospace communication modules

Conclusion

TRF-45 stands out as a high-reliability, low-loss PCB material that combines excellent electrical properties with outstanding thermal and mechanical stability. Whether you're developing next-generation communication devices or precision radar systems, TRF-45 provides the foundation for success.

Interested in using TRF-45 in your next project? Contact us today for technical support and custom PCB manufacturing services.
